The stainless 3000LB socket weld tee is the preferred fitting for the routing of fluid in pipelines used for the transmission of high pressure fluids. Its main features are as follows: It is produced from 304 or 316 grade stainless steel material in accordance with ASTM A182 standard. 3000 LB (pound-force per square inch) pressure class. It has a socket welded connection type, allowing the pipes to be joined tightly. Since it is welded, it has high sealing properties. Generally produced in diameters ranging from 1/4" to 2". Manufactured in accordance with ANSI B16.11 standard. It is used in industries such as food, chemistry, petrochemistry, pharmaceuticals.
1. Flow Diversion: Stainless socket weld tee is used to direct the flow in the pipeline in a specific direction. It can be used to distribute or divert the flow from one point of the pipeline in two different directions.
2. Dividing and Joining: Stainless socket weld tee functions to divide or join flow in the pipeline. It can be used to combine multiple pipelines into a single line or to divide and distribute flow from a single line to multiple lines.
3. Pipeline Arrangement: Stainless socket weld tee can be used to make specific adjustments to the pipeline such as height, routing or distribution. This ensures an optimized operation of the pipeline.
